1976 1977 - 1988 Johnson Evinrude Long 20" Lower Unit 40 45 48 50 55 60 HP 2 Cyl


$850.00
International Shipping Quote
  • Brand: Johnson Evinrude
  • Size: 40 45 48 50 55 60 HP
  • Color: Green
  • Style: 2 cylinder - 14/13 splines - Long
  • Condition: Used
  • Notes: 20" - Fully resealed
  • SKU: 53469 LRU
  • Manufacturer Part Number: 433571 0433571 396939 387107 388822 388475 0388475
  • Country of Manufacture: United States
  • Motor & Engine Type: Johnson Evinrude
  • Part Type: Motors, Engines & Components
  • Other Part Number: N/A
  • Surface Finish: Green
  • Inventory Number: 53469 LRU
  • Website Category: Lower Units
  • Website Sub Category: Complete Lower Units
  • UPC: N/A
  • Shipping: $75.00

Part Number

0433571 Supercede - 0396939 0387107 0388822 0388475

Key
Points
  • 20 Inch Driveshaft
  • Fully resealed
  • Extended Warranty with exchange of a spinning core(see below for more info)

Additional Info
  • Shifts and spins smoothly without binding
  • Shafts checked for straightness
  • Driveshaft splines show little to no wear
  • Gears & clutch are in good condition with light wear on clutch surfaces
  • Skeg has been reshaped and cleaned up
  • Freshwater Condition
  • New Impeller
  • Fully Resealed & Pressure checked to 12 PSI

Driveshaft splines: 14

Propeller shaft splines: 13

Driveshaft length from the top of the water pump to top of the shaft: 20-1/4"

Please add oil before use. This unit is shipped empty.

This lower unit qualifies for a 1 year warranty.  The warranty is validated by your core.  In order to qualify for this, you must send in that core.  Both shafts must spin and it must be complete.  We will send a label for you to return your core in our box after receipt of the unit you’ve purchased.  If you do not have a spinning core, you may call in after your purchase and buy the 1 year warranty for 10% of the purchase price.  If you do not return a core or purchase a warranty, this unit will be sold with a 45 day warranty and nothing more or less.

Location: Southcentral Outboards, Altamont, Illinois

Fits:

1976-1988 - 40 45 48 50 55 60 HP - 2 CYLINDER

We have provided this cross-reference with the resources we have available in regards to fitment. This most likely will not fit every model for the years and horsepowers we have listed. We urge you to make sure this is the exact item you need by matching the part number to what is required for your motor. If you need help doing so, please contact us prior to purchasing and we would be happy to help!
